TScale TR-I Series - SECTION 9 RS-232 OUTPUT

TR-I serial wireless crane scale user’s manual
- 11 -
SECTION 9 RS-232 OUTPUT
The TR-I Series of scales can be ordered with an optional RS-232 output.
9.1 Basic information
Specifications:
RS-232 output of weighing data
ASCII code
8 data bits
No Parity
Baud rate: 1200bps
9. 2 print out format
Format 1
NO. 3
G.W. 20.50kg
N.W. 18.30kg
Format 2
NO. 3
N.W. 18.30kg
Format 3
NO. 3
G.W. 20.50kg
N.W. 18.30kg
Format 4
NO. 3
N.W. 18.30kg
Format 5
NO. 3
N.W. 18.30kg
TOTAL 60.40kg
9. 3 continuously output protocol
con1: weighing mode
，
，
-/+
k
g
CR
LF
-HEADER1-- - HEADER2- --- WEIGHT DATA --
HEADER1: ST=STABLE， US=UNSTABLE
HEADER2: NT=NET， GS=GROSS
-WEIGHT UNIT-
TERMINATOR
