TScale TR-I Series - Section 2 Specifications

TR-I serial wireless crane scale user’s manual
- 2 -
SECTION 2 SPECIFICATIONS
Model
TR-I
Resolution
1/3,000
Capacity
1t/2t/3t/5t/10t
Interface
RS-232 Output Optional
Stabilisation Time
1 Seconds typical
Operating Temperature
0°C - 40°C / 32°F - 104°F
Power supply (external)
115 / 230 Vac, 120 / 240 Vac, 50/60Hz, 10 watts
Calibration
Automatic External
Display
6 digits 22mm LCD display, attached backlight
Housing
Indicator: ABS Plastic,
Crane scale: Stainless Steel
Zero range
0mV~5mV
Signal input range
0~15mV
ADC
Sigma delta
Internal counts
600,000
ADC update
Max 60 times /second
Load cell drive voltage
Max 5V/150mA
Load cells
Up to four 350 ohms cells
