TSI Instruments 4000 Series User Manual

55
SAZnnn
Sets the zero intercept for the analog output. The zero intercept nnn
is in units of mV. If nnn = 010, at zero flow the analog output will be
10 mV. This command will accept a negative offset formatted as
SZ-nnn. The zero adjustment range is –100 mV to 100 mV. Note that
this command sets the zero intercept only and is not a true “zero
adjust.” The analog output cannot go negative.
SAZ Denotes Set Analog Zero intercept.
nnn Denotes number of mV for the zero flow intercept.
Use the SAVE command to permanently store the new zero intercept
value as the new power-on default.
Example 1) SAZ030 Sets zero intercept of zero flow to +30 mV
Example 2) SAZ-050 Sets zero intercept of zero flow to –50 mV.
Note that the analog output cannot go negative.
SSRnnnn
Sets the sample rate that the data is returned at.
SSR Denotes set sample rate.
