TSI Instruments 4100 Series User Manual

24
Models 4021
through 4024
Models 4121
through 4122
Pressure Drop
See figure below See figure below
Instrument Temp.
Range
Operation, Ambient
Storage, Ambient
0 to 50°C
-20 to 60°C
0 to 50°C
-20 to 60°C
Gas Calibrations
Flowmeter must be
calibrated to the
specified gas. Consult
factory.
Flowmeter must be
calibrated to the
specified gas. Consult
factory.
Physical
Dimensions
External Dimensions
Inlet/Outlet Options
Weight
Flow Body Material
Wetted materials
See Chapter 3
.
See Chapter 3
.
170 grams
Polycarbonate
Polycarbonate, gold,
platinum, alumina, Sn/Pb
solder
See Chapter 3
.
See Chapter 3
.
63 grams
Polycarbonate
Polycarbonate, gold,
platinum, alumina,
Sn/Pb solder
Power
Requirements
Power supplied through
interface connector.
5.0 VDC ±0.25 V, 300
mA maximum
Power supplied through
interface connector.
5.0 VDC ±0.25 V, 300
mA maximum.
