TSI Instruments 4100 Series

16
Pin-out for Mini-DIN Connector
Mini-DIN pin-out and cable color code
Mini-DIN
Pin No. Function
Color code for
TSI cable with
tinned wires.
PN 1303584
Computer
female 9 pin
D-Sub
1
Power Input (+5V) Black
2
Power Ground Green
3
Analog Output (+) Red
4
Analog Ground (-) Brown
5
Analog Pressure Input
(+)
Blue
6
RS-232 Receive (in) White 3
7
RS-232 Transmit (out) Yellow 2
8
Logic Ground Gray 5
