TSI Instruments FHC50 User Manual

Appendix B
84
Standard Object Types Supported:
Dynamically
Createable
Dynamically
Deletable
Optional
Properties
Supported
Writable
Properties (Data
Type)
Analog Input
No
No
Analog Value
No
No
Present_Value
(Real)
Binary Input
No
No
Active_Text,
Inactive_Text
Binary Value
No
No
Active_Text,
Inactive_Text
Present_Value
(Enumerated)
Multi-state Input
No
No
State_Text
Multi-state Value
No
No
State_Text
Present_Value
(Unsigned Int)
Device Object
No
No
Object Name
(Char String)
Max Master
(Unsigned Int)
Data Link Layer Options:
 BACnet IP, (Annex J)
 BACnet IP, (Annex J), Foreign Device
 ISO 8802-3, Ethernet (Clause 7)
 ANSI/ATA 878.1, 2.5 Mb. ARCNET (Clause 8)
 ANSI/ATA 878.1, RS-485 ARCNET (Clause 8), baud rate(s)
 MS/TP master (Clause 9), baud rate(s): 76.8k 38.4k, 19.2k, 9600 bps
 MS/TP slave (Clause 9), baud rate(s):
 Point-To-Point, EIA 232 (Clause 10), baud rate(s):
 Point-To-Point, modem, (Clause 10), baud rate(s):
 LonTalk, (Clause 11), medium:
 Other:
Device Address Binding:
Is static device binding supported? (This is currently necessary for two-way communication with MS/TP
slaves and certain other devices.) Yes  No
Networking Options:
 Router, Clause 6 - List all routing configurations, e.g., ARCNET-Ethernet, Ethernet-MS/TP, etc.
 Annex H, BACnet Tunneling Router over IP
 BACnet/IP Broadcast Management Device (BBMD)
Character Sets Supported:
Indicating support for multiple character sets does not imply that they can all be supported
simultaneously.
 ANSI X3.4  IBM
®
/Microsoft
®
DBCS  ISO 8859-1
 ISO 10646 (UCS-2)  ISO 10646 (UCS-4)  JIS C 6226
If this product is a communication gateway, describe the types of non-BACnet
®
equipment/networks(s) that the gateway supports:
Not Applicable
