TSI Instruments FHC50 User Manual

BACnet
®
MS/TP Object Set 85
BACnet
®
MS/TP Object Set
Feature
Object
Type
Device
Instance
Units
Range
Read/
Write
Notes
Face Velocity
Analog
Input
1
fpm
0 to 1000
R
m/s
0 to 5.08
Flow Rate
Analog
Input
2
cfm
0 to 10000
R
m
3
/h
0 to 16990
l/s
0 to 4719
Damper or Valve
Position
Analog
Input
3
%
0 to 100
R
Sash Position
Percent
Analog
Input
4
%
0 to 100
R
Sash Open Area
Analog
Input
5
ft
2
0 to 1000
R
m
2
0 to 93
MAC Address
Analog
Value
1
-
1 to 127
R/W
Communications
will be lost until
front-end updated
with new MAC
Address
MAC ID**
(1
st
4 digits)
Analog
Value
2
N/A
1 to 4,194
R/W
Normal Face
Velocity Setpoint
Analog
Value
3
fpm
0, 60 to 1000
R/W
m/s
0, 0.03 to 5.08
Setback Face
Velocity Setpoint
Analog
Value
4
fpm
0, 60 to 1000
R/W
m/s
0, 0.03 to 5.08
Normal Low Face
Velocity Alarm
Setpoint
Analog
Value
5
fpm
0, 5 to 980
R/W
m/s
0, 0.03 to 4.98
Normal High
Face Velocity
Alarm Setpoint
Analog
Value
6
fpm
0, 80 to 1000
R/W
m/s
0, 0.42 to 5.08
Setback Low
Face Velocity
Alarm Setpoint
Analog
Value
7
fpm
0, 5 to 980
R/W
m/s
0, 0.03 to 4.98
Setback High
Face Velocity
Alarm Setpoint
Analog
Value
8
fpm
0, 80 to 1000
R/W
m/s
0, 0.42 to 5.08
Normal Flow
Setpoint
Analog
Value
9
cfm
0 to 10000
R/W
m
3
/h
0 to 16990
l/s
0 to 4719
Setback Flow
Setpoint
Analog
Value
10
cfm
0 to 10000
R/W
m
3
/h
0 to 16990
l/s
0 to 4719
Normal Low Flow
Alarm Setpoint
Analog
Value
11
cfm
0 to 10000
R/W
m
3
/h
0 to 16990
l/s
0 to 4719
Normal High
Flow Alarm
Setpoint
Analog
Value
12
cfm
0 to 10000
R/W
m
3
/h
0 to 16990
l/s
0 to 4719
