TSI Instruments FHC50 User Manual

Appendix B
86
Feature
Object
Type
Device
Instance
Units
Range
Read/
Write
Notes
Setback Low
Flow Alarm
Setpoint
Analog
Value
13
cfm
0 to 10000
R/W
m
3
/h
0 to 16990
l/s
0 to 4719
Setback High
Flow Alarm
Setpoint
Analog
Value
14
cfm
0 to 10000
R/W
m
3
/h
0 to 16990
l/s
0 to 4719
Min. Damper
Position
Analog
Value
15
%
0 to 100
R/W
Max. Damper
Position
Analog
Value
16
%
0 to 100
R/W
Minimum Flow
Setpoint
Analog
Value
17
cfm
0 to 10000
R/W
m
3
/h
0 to 16990
l/s
0 to 4719
Maximum Flow
Setpoint
Analog
Value
18
cfm
0 to 10000
R/W
m
3
/h
0 to 16990
l/s
0 to 4719
Setback Damper
Position Setpoint
Analog
Value
19
%
0 to 100
R/W
High Sash
Position Alarm
Setpoint
Analog
Value
20
%
0, 10 to 105
R/W
MAC ID**
(Last 3 digits)
Analog
Value
21
N/A
1 to 999
R/W
Communications
will be lost until
front-end updated
with new MAC
Address
Low Velocity
Alarm Status
Binary
Input
1
0: Inactive
1: Active
0;1
R
High Velocity
Alarm Status
Binary
Input
2
0: Inactive
1: Active
0;1
R
Low Flow Alarm
Status
Binary
Input
3
0: Inactive
1: Active
0;1
R
High Flow Alarm
Status
Binary
Input
4
0: Inactive
1: Active
0;1
R
High Sash
Position Alarm
Status
Binary
Input
5
0: Inactive
1: Active
0;1
R
Velocity Sensor
Error Status
Binary
Input
6
0: Inactive
1: Active
0;1
R
Data Error Status
Binary
Input
7
0: Inactive
1: Active
0;1
R
Setback Status
Binary
Input
8
0: Inactive
1: Active
0;1
R
Emergency
Status
Binary
Input
9
0: Inactive
1: Active
0;1
R
Auto Baud
Multi-State
1
0: No Action
1 Set Auto Baud
0;1
R/W
Controller will
reset variable to
0 after setting
baud rate.
