p. 7 of 16

NOTE: Number of sensors will vary per application.

Figure 9. Pressure Transducer Sensors Wiring to Model RPM10 / RPM20

NOTE: Model RPM10 does not support Room 2 or Anteroom Pressure Transducer Sensors.

RPM20-CC only does not support Room 2 or Anteroom Pressure Transducers when

configured for use with Remote with Pump Particle Counter.

NOTE: Number of sensors will vary per application.
