p. 8 of 16

Figure 10. Optional Supply / Exhaust Flow Switch Wiring to Model RPM10 / RPM20

NOTE: RPM20-CC does not support Exhaust Flow Switch when configured for use with

Remote with Pump Particle Counter.

Figure 11. Optional Supply / Exhaust Pressure-Based Flow Station Wiring to Model RPM10 / RPM20

NOTE: RPM20-CC does not support Exhaust Pressure-Based Flow Station when configured for

use with Remote with Pump Particle Counter.
