p. 9 of 16

Figure 12. Optional Supply / Exhaust Linear Flow Station Wiring to Model RPM10 / RPM20

NOTE: RPM20-CC does not support Exhaust Linear Flow Station when configured for use with

Remote with Pump Particle Counter.

Figure 13. Optional Supply / Exhaust Venturi Valve Wiring to Model RPM10 / RPM20

NOTE: RPM20-CC does not support Exhaust Venturi Valve when configured for use with

Remote with Pump Particle Counter.
