TSI Instruments QUESTemp 32 - Up and Running; Check Wick and Fill Natural Wet Bulb

1 Up and Running
Check Wick and Fill Natural Wet Bulb
Up and Running
1. Make sure the wet bulb’s wick is clean. Fill the reservoir with distilled
water. (DO NOT use ordinary tap water).
2. Place the QUESTemp° in the work area in a safe location approximately
3.5 feet off the ground.
3. Turn the unit ON. If the battery voltage displayed during the power-on
sequence is less than or equal to 6.4 volts, replace or recharge the
batteries.
4. Use the arrow keys to set the display to the desired items.
5. Allow 10 minutes for the sensors to stabilize to the environment before
taking readings.
Check Wick and Fill Natural Wet Bulb
The QUESTemp 32 uses a cotton wick immersed into a reservoir containing distilled
water. DO NOT use ordinary tap water, as the contaminants that are left behind
after evaporation will shorten the life of the wick and cause high readings. If the wick
is discolored, it should be replaced. To replace the wick, slide the old wick off the
top of the sensor. Place a new wick over the sensor, making sure that the bottom of
the wick is down in the reservoir.
Wick
Reservoir cover
Reservoir
Filling wet bulb reservoir
1. Remove reservoir cover and fill with
distilled or de-ionized water.
2. Replace reservoir cover.
Figure 1-1: Filling wet bulb reservoir
Up and Running
