TTI TCB-550 - Part List

SECTION3 PART LIST
NO LEVEL P/N DESCRIPTION QTY
1 ASSY 5A0-5504-000
LCD PCB ASS′Y - TCB550
1.00
2 PART 102-331J-S00 FILM RES. 330OHM 0.5W +-5 ST 1.00
3 PART 102-471J-S00 FILM RES. 470OHM 0.5W +-5 ST 1.00
4 PART 142-100J-000 CHIP RES. 0603 10OHM +-5 PHILIPS 1.00
5 PART 142-102J-000 CHIP RES. 0603 1KOHM +-5 PHILIPS 1.00
6 PART 142-104J-000 CHIP RES. 0603 100KOHM +-5 PHILIPS 1.00
7 PART 142-105J-000 CHIP RES. 0603 1MOHM +-5 PHILIPS 1.00
8 PART 142-222J-000 CHIP RES. 0603 2.2KOHM +-5 PHILIPS 1.00
9 PART 142-223J-000 CHIP RES. 0603 22KOHM +-5 PHILIPS 1.00
10 PART 142-472J-000 CHIP RES. 0603 4.7KOHM +-5 PHILIPS 4.00
11 PART 142-473J-000 CHIP RES. 0603 47KOHM +-5 PHILIPS 29.00
12 PART 212-102B-3K0 CHIP CERAMIC CAP.0603 0.001UF X7R 16V +-10 PHILIPS 2.00
13 PART 212-103B-3K0 CHIP CERAMIC CAP. 0603 0.01UF X7R 16V +-10 PHILIPS 1.00
14 PART 212-105F-3Z0 CHIP CERAMIC CAP. 0603 1UF Y5V 16V -20+80 PHILIPS 2.00
15 PART 212-470C-6J0 CHIP CERAMIC CAP. 0603 47PF NP0 50V +-5 PHILIPS 2.00
16 PART 305-0226-000 CHIP TR. KRA226S KEC 1.00
17 PART 305-0401-000 CHIP TR. KRC401E KEC 1.00
18 PART 305-0404-000 CHIP TR. KRC404E KEC 1.00
19 PART 320-0509-006 IC CPU(FLASH) JT5BL9 TOSHIBA - TCB550 1.00
20 PART 338-2402-A00 IC EEPROM FT24C02A FMD 1.00
21 PART 350-0603-001 CHIP LED BLUE 0603 19-217 BHC-CLEM2RY 3T YADA 4.00
22 PART 352-4686-000 LCD SDM8A4686A SANTECH 1.00
23 PART 363-0800-000 CRYSTAL 8.0MHZ 49S-8.000-20-30 SHOULDER 1.00
