Transmit
---
---
---
Transmit
CH 1 , 13.4825 MHz
CH 40 , 13.7025 MHz
26.965 MHz
27.405 MHz
Since all frequencies are obtained from the crystal controlled PLL oscillator, all outputs are
coherent with the crystal oscillator frequency and matching the same percentage accuracy.
