ENGLISH
Installing An Antenna
It is very important to select a good quality high efficiency 27MHz
antenna. A poor quality antenna or one not designed for the
27MHz band will give very poor performance and could cause
damage to the transceiver.
Warning : Never try the operation of your transceiver before
connecting a proper antenna in order not to cause any damage.
Place the antenna as high as possible.
The longer the antenna is, normally the better is the
performance of the transceiver.
Try
to mount the antenna in the centre of the surface that you
select.
Make sure that you have a solid metal-to-metal ground
co
nnection.
Be
careful not to damage the cable during the installation.
1)
2)
3)
4)
5)
5
TCB-560
