TuffStuff AXT-5S - Page 10

Assembly List
Item # Description Qty.
20 LAT BAR HOLDER 1
45 TOP FRAME 1
59 ACCESSORY HOLDER 1
64 PULLEY 3/8 X 1 1/2 X 4 1/2 (WIDE) 1
77 CUP HOLDER 1
101 FLAT WASHER SAE B/O 3/8” 9
114 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 1/4 1
116 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 1/4 2
118 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 4 1/2 1
133 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 1
134 NYLON INSERT LOCK NUT B/O 3/8-16 3
137 NYLON INSERT JAM LOCK NUT B/O 3/8-16 1
166 SPLIT LOCK WASHER B/O 3/8” 1
176 FLAT HEAD SOC CAP SCREW B/O # 12-28 X 3/4 4
180 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 4 3/4 1
Step 4
10 AXT-5S_AXT-5D AXT- Pro-Style Home Gym
