TuffStuff AXT-5S - Parts List; AXT-5 D Parts List

ITEM # DESCRIPTION PART # QTY. ITEM # DESCRIPTION PART # QTY.
1 ADD ON WEIGHT 2.5 LBS UP3700 1 45 TOP FRAME UP3726 1
2 ADD ON WEIGHT 5 LBS UP3701 1 46 TOP FRAME REINFORCEMENT PLATE LT UP3727 1
3 ADJUSTABLE BACK PAD BRACKET UP3703 1 47 TOP FRAME REINFORCEMENT PLATE RT UP3728 1
4 ADJUSTABLE DOUBLE PULLEY BRACKET UP3704 2 48 TOP GUIDE ROD RETAINER UP3729 1
5 ADJUSTABLE PRESS BAR RELEASE ASSEMBLY UP3786 1 50 WEIGHT SHROUD UP3795 2
5a PRESS BAR RELEASE LEVER BNH1775 1
51 LAT CABLE (184 3/4”) UP3790 1
5b PIN PLUNGER 1/2 X 3 1/2 (1/4-20 THREAD) BNH1774 1
52 AB/LOW ROW CABLE (216 1/4”) UP3792 1
5c RETAINING NUT 25/64 X 3/4-10 K-103 BNH0181 1
53 LEG EXTENSION CABLE (92 1/4”) UP3793 1
5d PULL PIN STIFF SPRING 17/32 X 1 1/2 BNH1776 1
54 PEC FLY CABLE (91 1/4”) UP3791 1
5e RETAINING SNAP RING EXT. 1/2 BNH1154 1
55 TENSION CABLE (113 1/2”) UP3794 1
5f NYLON INSERT JAM LOCK NUT 3/8-16 BNH0365 2
56 PRESS BAR PIVOT AXLE 1 X 5 3/4 UP3796 1
6 ADD ON WEIGHT LOCK UP3702 2 57 LEG EXTENSION PIVOT AXLE 1 X 3 1/4 UP3797 1
7 BACK PAD UP3705 1
58 ABDOMINAL STRAP BNH0821 1
8 BOTTOM FRAME UP3706 1
59 ACCESSORY HOLDER BNH1764 1
9 BOTTOM GUIDE ROD RETAINER UP3707 1
60 ALUMINUM CAM PLATE 3/4 X 5” BNH1153 2
10 CABLE RETAINER BRACKET (3 1/2 PULLEY) UP0998 1
61 ALUMINUM CAP 1.020” RD (CAP-100) BNH0537 2
11 CHROME GUIDE ROD 3/4 X 73 5/8 UP3731 2
62 ALUMINUM CAP 1.270” RD BNH0538 6
12 ADJUSTABLE SINGLE PULLEY BRACKET UP3708 1
63 ALUMINUM FOOT ROLL HOLDER 1 5/16 ID X 3 OD BNH1792 16
13 FOAM FOOT ROLL 1 X 4 X 7 W/VINYL UP3785 8
64 ALUMINUM PULLEY 3/8 X 1 1/2 X 4 1/2 BNH1695 4
14 FOAM ROLL TUBE 1 X 19 7/8 UP3709 2
65 ALUMINUM PULLEY 3/8 X 1 X 3 1/2 BNH1266 5
15 FOAM ROLL TUBE 1 X 26 3/8 UP3710 1
66 ALUMINUM PULLEY 3/8 X 1 X 4 1/2 BNH0069 18
16 FOOT SUPPORT UP4911 1
67 ALUMINUM WASHER .390 ID X 1.500 OD BNH1541 8
17 FRONT UPRIGHT UP3711 1
68 ANKLE STRAP BNH1435 1
18 GRAVITY LATCH UP4396 1
69 BEARING 6203 W/BUSHING BNH0843 2
19 LAP HOLD-DOWN ASSY UP3588 1
70 BRONZE BUSHING 1 X 1.260 X 1.496 X 0.531 X 0.118 BNH1815 8
20 LAT BAR HOLDER UP3744 1
71 BRONZE BUSHING 1/2 X 5/8 X 1/2 X 7/8 X 1/8 BNH0528 4
21 LEG EXT ACTUATOR PLATE UP3712 1
72 BUTTON HEAD SOCKET CAP SCREW 3/8-16 X 1 BNH0115 15
22 LEG EXT ACTUATOR THREADED PLATE UP3713 1
73 BUTTON HEAD SOCKET CAP SCREW 3/8-16 X 1 1/4 BNH0896 2
23 LEG EXT/LEG CURL RATCHET ASSY HOUSING UP4912 1
74 CABLE ANCHOR CLIP BNH1784 1
24 LONG ADJUSTABLE STOPPER UP0331 3
75 CHROME WASHER 3/8 X 1 1/2 BNH1015 10
25 LOW ROW FRAME CONNECTOR ASSEMBLY UP3716 1
76 COIL CHAIN Z/P 3/16 X 21 BNH1262 1
26 OFF SET DOUBLE PULLEY BRACKET UP3717 1
77 CUP HOLDER BNH1763 1
27 PEC DEC ARM LEFT SIDE UP0819 1
78 DECAL-ADD-ON 2.5 LBS. BNH1757 1
28 PEC DEC ARM RIGHT SIDE UP0818 1
79 DECAL-ADD-ON 5 LBS. BNH1756 1
29 PIVOT ARM UP3590 1
80 DECAL-ADJUST CABLE HERE BNH1751 4
30 PRESS BAR UP3620 1
81 DECAL-ADJUSTMENT BACK PAD BNH1749 1
31 PRESS BAR HOUSING UP3718 1
82 DECAL-ADJUSTMENT PRESS BAR BNH1748 1
33 REAR UPRIGHT UP3621 1
83 DECAL-AXT-5 BNH1755 1
34 REINFORCEMENT PLATE 1/4 X 2 X 5 (BEND) UP3719 2
84 DECAL-CAUTION FOR CHINNING (1 1/4 X 2 3/4) BNH1742 1
35 REINFORCEMENT PLATE 1/4 X 2 X 7 (BEND) UP3720 1
85 DECAL-CAUTION WEIGHT TRAINING BNH1743 1
36 RELEASE LAP HOLD-DOWN ASSY UP3589 1
86 DECAL-DANGER TIGHTEN THIS RET..., 3/4 X 1 1/2 BNH1745 4
37 HANDLES UP3618 2
87 AXT-5 USER’S MANUAL OS0282 1
38 SEAT FRAME UP3723 1
88 DECAL-FOR BEST PERFORMANCE BNH1750 1
39 SEAT PAD UP3724 1
89 DECAL-WARNING KEEP HANDS AND FINGERS... BNH1744 1
40 SELECTOR PIN W/COIL 3/8 X 4 UP3035 1
90 DECAL-WEIGHT NUMBERS REF TP-10 (200 lbs) BNH1542 1
41 STOPPER HOUSING BLOCK (LARGE) UP3746 1
91 FINISHED HEX NUT 1/2-13 BNH0201 8
42 STOPPER HOUSING BLOCK (SMALL) UP3745 1
92 SPACER 0.406 IDX 0.630 OD X 0.748 L BNH1802 2
43 SWIVEL FOOT ROLL HOLDER UP4397 1
93 FLANGE SPACER 0.406 X 0.63 X 1.595 BNH1778 2
44 SWIVEL HANDLE UP3725 2
94 FLANGE SPACER 0.406 X 0.63 X 1.633 BNH1777 2
AXT-5D
Parts List
CHART
BOLD FONT = SUB-ASSEMBLY PARTS
REGULAR FONT = HARDWARE
44 AXT-5S_AXT-5D AXT- Pro-Style Home Gym
