ITEM # DESCRIPTION PART # QTY. ITEM # DESCRIPTION PART # QTY.
95 FLAT HEAD SOCKET CAP SCREW 3/8-16 X 1 1/2 BNH0636 1 148 RUBBER BUMPER W/WASHER 3/8 X 1 1/2 BNH0514 2
96 FLAT HEAD SOCKET CAP SCREW 3/8-16 X 2 1/4 BNH1759 1 149 RUBBER CONE 1 ID X 3 OD X 1 1/8 BNH1451 2
97 FLAT HEAD SOCKET CAP SCREW 5/16-18 X 2 3/4 BNH1758 1 150 RUBBER CORR MAT 1/8 X 4 X 12 1/2 BNH0688 2
98 FLAT HEAD SOCKET CAP SCREW 12-32 X 1/2 BNH1786 3 151 RUBBER DONUT 3/4 X 2 1/2 BNH0068 2
99 FLAT PHILLIPS SCREW ZINC # 2 X 1/2 BNH1480 4 152 RUBBER FOOT FOR 6 X 4 1/4 PLATE BNH1647 3
100 FLAT WASHER SAE 1/2” BNH0238 7 153 RUBBER GRIP 1 ID X .125 X 5 1/4 BNH1128 2
101 FLAT WASHER SAE 3/8” BNH0239 115 154 RUBBER GRIP 1.1875 ID X .125 X 4 1/4 BNH0936 4
103 FLAT WASHER USS 1/4” BNH0233 4 155 RUBBER GRIP 1.1875 ID X .125 X 5 BNH1809 4
104 HEX HEAD CAP SCREW GR-5 1/2-13 X 3 3/4 BNH0297 1 156 RUBBER GRIP 1/2 X 4 BNH0530 2
105 HEX HEAD CAP SCREW GR-5 1/2-13 X 4 1/2 BNH0265 1 157 RUBBER GROMMET 3/4” ID (2867-012) BNH0401 2
106 HEX HEAD CAP SCREW GR-5 1/2-13 X 5 BNH0268 1 158 SHOULDER BOLT 3/8 X 3/4 BNH0718 4
107 HEX HEAD CAP SCREW GR-5 1/2-13 X 6 1/4 BNH0270 1 159 SNAP LINK Z/P 8MM X 80MM BNH0065 4
108 HEX HEAD CAP SCREW GR-5 1/4-20 X 3/4 BNH0890 4 160 SOCKET HEAD CAP SCREW 1/4-20 X 3/4 BNH0452 2
109 HEX HEAD CAP SCREW GR-5 3/8-16 X 1 1/2 BNH0303 4 161 SOCKET SET SCREW 1/4-20 X 1/4 BNH0790 2
111 HEX HEAD CAP SCREW GR-5 3/8-16 X 1 3/4 BNH0274 18 162 SOCKET SET SCREW 10-32 X 1/8 BNH0473 48
112 HEX HEAD CAP SCREW GR-5 3/8-16 X 2 BNH0279 3 163 SOCKET SET SCREW 3/8-16 X 3/4 BNH0476 6
113 HEX HEAD CAP SCREW GR-5 3/8-16 X 2 1/2 BNH0276 2 164 SPLIT COLLAR 1” BNH0755 2
114 HEX HEAD CAP SCREW GR-5 3/8-16 X 2 1/4 BNH0277 2 165 SPLIT HEX TAP BOLT GR-5 1/2-13 X 3 1/2 BNH1131 2
115 HEX HEAD CAP SCREW GR-5 3/8-16 X 2 3/4 BNH0278 1 166 SPLIT LOCK WASHER 3/8” BNH0658 28
116 HEX HEAD CAP SCREW GR-5 3/8-16 X 3 1/4 BNH0312 8 167 HEX KEY 3/32” BNH0372 1
118 HEX HEAD CAP SCREW GR-5 3/8-16 X 4 1/2 BNH0284 5 168 SPLIT LOCK WASHER Z/P 1/2” BNH0572 5
119 HEX HEAD CAP SCREW GR-5 3/8-16 X 4 BNH0285 2 169 STRAP BRACKET 20 #SF20 STAINLESS STEEL BNH0562 5
120 HEX HEAD CAP SCREW GR-5 3/8-16 X 5 BNH0320 11 170 TORSION SPRING BNH1773 1
121 HEX HEAD CAP SCREW GR-5 3/8-16 X 5 1/4 BNH0690 8 171 TUFFSTUFF LOGO ALUMINUM SMALL BNH1323 2
122 HEX HEAD CAP SCREW GR-5 3/8-16 X 3/4 BNH0283 4 172 URETHANE BUMPER 1 3/4 BNH0229 4
123 HEX HEAD CAP SCREW GR-5 3/8-16 X 3 BNH0282 4 173 URETHANE BUMPER 962 BNH0244 3
124 HEX KEY 7/32” BNH0575 2 174 U-STYLE TAPPED HOLE NUT 1/4-20 BNH0708 4
125 HEX KEY ARM 1/8” BNH0767 1 175 WEIGHT STACK LID BNH1693 1
126 HEX KEY ARM 3/16” BNH0371 1 176 FLAT HEAD SOCKET CAP SCREW # 12-28 X 3/4 BNH1787 4
127 LAT BAR 1 1/4 ALUMINUM BNH1770 1 177 10 LB STEEL WEIGHT PLATE BLACK 4 9/16 X 9 7/16 BNH1650 19
128 LEG EXTENSION/LEG CURL ALUMINUM CAM BNH1783 1 178 STEEL BUMPER WASHER Z/P 1/2” BNH1800 4
129 LOW ROW BAR 1 1/4 ALUMINUM BNH1771 1 179 PLASTIC END CAP BLACK-BUMPER BNH1801 4
130 METAL HINGE BNH0046 2 180 NYLON FLAT WASHER 1 X 1 1/4 X 1/16 BNH0393 9
131 NYLON BALL 1 3/4 X 5/16 BNH0022 4 181 NYLON STEM BUTTON BNH0533 1
132 NYLON BUSHING 1 X 1 1/2 X 7/8 X 1 3/4 X 1/8 BNH0531 4 182 BLACK GRIP 1/2 X 4 7/8 BNH1818 1
133 HEX HEAD CAP SCREW GR-5 3/8-16 X 1 BNH0275 2 183 BRONZE BUSHING 1 X 1 1/4 X 3/4 X 1 1/2 X 1/8 BNH0527 8
134 NYLON INSERT LOCK NUT 3/8-16 BNH0214 32 184 RELEASE LAP HOLD-DOWN PROTECTIVE CAP BNH1817 1
135 NYLON INSERT LOCK NUT 5/16-18 BNH0215 4
136 NYLON INSERT JAM LOCK NUT 1/2-13 BNH0366 4
AXT-5S
137 NYLON INSERT JAM LOCK NUT 3/8-16 BNH0365 26
138 NYLON SPACER 3/8 X 3/4 X 3/8 BNH0392 2
Parts List
139 PLASTIC COVER RATCH HOUSING BNH1785 1
140 PLASTIC INSERT CAP 1 1/4” RD 11 GA BNH0573 6
All parts same as AXT-5D, except for the parts listed below
141 PLASTIC INSERT CAP 2” RD 10-14 GA BNH0004 3 ITEM # DESCRIPTION PART # QTY.
142 PLASTIC INSERT CAP 2” SQ 10-14 GA BNH0012 2
40 SELECTOR PIN W/COIL 3/8 X 3 1/4 UP3051 1
143 PLASTIC STOPPER BNH1765 1 64 NYLON PULLEY 3/8 X 1 1/2 X 4 1/2 BNH1694 4
144 PULL PIN 1/2 X 3 1/2 (YELLOW KNOB) BNH0603 2 65 NYLON PULLEY 3/8 X 1 X 3 1/2 BNH0553 14
145 PULL PIN 1/2 X 5 5/8 (YELLOW KNOB) BNH0701 1 66 NYLON PULLEY 3/8 X 1 X 4 1/2 BNH0506 19
146 PVC 1 X 8 BNH0417 8 147 10 LB TOP PLATE W/ADJ. SLTR BAR 19 WTS BNH1100 1
147 10 LB TOP PLATE/SELECTOR BAR BLACK BNH1239 1 177 10 LB CAST WEIGHT PLATE GREY BNH0904 19
AXT-5D
Parts List
CHART
BOLD FONT = SUB-ASSEMBLY PARTS
REGULAR FONT = HARDWARE
45AXT-5S_AXT-5D AXT- Pro-Style Home Gym
