TuffStuff AXT-5S - Tension Cable Assembly

Assembly List
Item # Description Qty.
55 TENSION CABLE (113 1/2”) 1
101 FLAT WASHER SAE B/O 3/8” 2
111 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4 1
131 NYLON BALL 1 3/4 X 5/16 1 135 NYLON INSERT LOCK NUT B/O 5/16-18 1 137 NYLON INSERT JAM LOCK NUT B/O 3/8-16 1 158 SHOULDER BOLT ALLOY 3/8 X 3/4 1 159 SNAP LINK Z/P 8MM X 80MM 1 163 SOCKET SET SCREW ALLOY 3/8-16 X 3/4 1 169 STRAP BRACKET 20 #SF20 STAINLESS STEEL 2
Step 16 Tension Cable Assembly
169 158
135
163
169
55
131
113 1/2”
34 AXT-5S_AXT-5D AXT- Pro-Style Home Gym
