TuffStuff AXT-5S - Ab;Low Row Cable Assembly

Assembly List
Item # Description Qty.
12 ADJUSTABLE SINGLE PULLEY BRACKET 1 26 OFF SET DOUBLE PULLEY BRACKET 1 52 AB/LOW ROW CABLE (216 1/4”) 1
131 NYLON BALL 1 3/4 X 5/16 2 135 NYLON INSERT LOCK NUT B/O 5/16-18 2 158 SHOULDER BOLT ALLOY 3/8 X 3/4 2 159 SNAP LINK Z/P 8MM X 80MM 2 163 SOCKET SET SCREW ALLOY 3/8-16 X 3/4 2 169 STRAP BRACKET 20 #SF20 STAINLESS STEEL 2
Step 13 Ab/Low Row Cable Assembly
158
163 131
131 163
169
135
135
169
158
52
216 1/4”
LEFT SIDE VIEW
28 AXT-5S_AXT-5D AXT- Pro-Style Home Gym
