TuffStuff AXT-5S - Page 12

Assembly List
Item # Description Qty.
46 TOP FRAME REINFORCEMENT PLATE LT 1
47 TOP FRAME REINFORCEMENT PLATE RT 1
66 PULLEY 3/8 X 1 X 4 1/2 2
92 SPACER 0.406 ID X 0.63 OD X .0748 L 2
101 FLAT WASHER SAE B/O 3/8” 20
113 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 1/2 2
120 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 5 9
134 NYLON INSERT LOCK NUT B/O 3/8-16 9
143 PLASTIC STOPPER 1
166 SPLIT LOCK WASHER B/O 3/8” 2
Step 5
12 AXT-5S_AXT-5D AXT- Pro-Style Home Gym
