TuffStuff AXT-5S - Step 3: Front Upright and Seat Frame

Assembly List
Item # Description Qty.
17 FRONT UPRIGHT 1
24 LONG ADJUSTABLE STOPPER 1
38 SEAT FRAME 1
64 PULLEY 3/8 X 1 1/2 X 4 1/2 (WIDE) 3
91 FINISHED HEX NUT B/O 1/2-13 2
100 FLAT WASHER SAE B/O 1/2” 1
101 FLAT WASHER SAE B/O 3/8” 18
114 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 1/4 1
116 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 1/4 4
118 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 4 1/2 2
119 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 4 2
134 NYLON INSERT LOCK NUT B/O 3/8-16 6
137 NYLON INSERT JAM LOCK NUT B/O 3/8-16 3
168 SPLIT LOCK WASHER Z/P 1/2” 1
Step 3
8 AXT-5S_AXT-5D AXT- Pro-Style Home Gym
