Tunturi C20 - Page 7

7
C-20
D-1
24
57
57
117 Curved Washer
φ17*φ25*1T (2)
116 Carriage Bolt M8*60L(4)
115 Curved Washer
φ8*φ19*2T (4)
114 Carriage Bolt M8*16L(8)
113 allen bolt M5*10L(4)
112 Curved Washer
φ8.5*φ25*2T (4)
111 Spring Washer
φ8*2T(2)
122 Knob (foot pedal)M6xP1.0(4)
123 Carrage bolt M6*P1.0*60L(black) (4)
125 Flat washer φ6*φ16*2T(4)
Spring Washer Ø6*2t(4)
S-15
124 Spring Washer φ6*2T(4)
Box Spanner(1)
Allen Key(1)
Allen Key(1) 5MM
