Tunturi C20 - Page 8

8
C-20
D-2
24
88
116
115
95
117
Curved Washer
φ17*φ25
*
1T
(2)
116 Carriage Bolt M8*60L(4)
115 Curved Washer
φ8*φ19*2T (4)
114 Carriage Bolt
M8*16L(8)
113 allen bolt
M5*10L(4)
112
Curved Washer
φ8.5*φ25
*
2T
(4)
111 Spring Washer
φ8*2T
(2)
122 Knob (foot pedal)M6xP1.0(
4
)
4) 4
123 Carrage bolt M6*P1.0*60L(black) (4)
125 Flat washer
φ
6*
φ
16*2T(
4
)
4)4
Spring Washer Ø6*2t(4)
S-15
124 Spring Washer
φ
6*2T(
4
)
4)4
Box Spanner(1)
Allen Key(1)
Allen Key(1) 5MM
