Copyright by Tunturi Oy Ltd 22 All information subject to changes
TUNTURI
SERVICE MANUAL
_____________________________________________________________________________________ Version 1/2000
Technical information
Gas spring push force 2000 N
9 FOLDAWAY
9.1 Gas spring
9.1.1 Replacing
The upper end of the gas spring is attached to brackets in the frame. The upper end is released
from the brackets when the lifted-up running base is pushed further upwards. The lower end of
the spring can be removed from the Foldaway-frame by removing the quick locking sleeves from
the ends of the axle. The sleeves must be changed when replacing the gas spring.
