Copyright by Tunturi Oy Ltd APPENDIX 1 / Page 1/(2) All information subject to changes
TUNTURI
SERVICE MANUAL
_____________________________________________________________________________________________________Version 1/2000
PRODUCT NUMBERS:
J6 320000 Owner’s Manual 583 4024 (two 4-language
versions with same #)
J6F 320005
TECHNICAL DATA:
Length: 153 cm (Storage position / FoldAway 70 cm)
Height: 142 cm (Storage position / FoldAway 155 cm)
Foot print area: 1,45 m² (Storage position / FoldAway 0,62 m²)
Width: 82 cm
Weight: 80 kg
Running surface: 135 cm x 46 cm
Running surface height: 26 cm (floor to running surface level, 0 % inclination)
Package size: 175 cm x 100 cm x 40 cm; 90 kg; 0,70 m³
Max. user weight: 135 kg
Tread motor: 1,8 HP / 1,34 kW (continuous duty), max. speed approx.
3400 RPM,
nominal voltage 130 VDC, overcurrent protector
Speed range: 0,5-16 km/h
Operating voltage: primary 230 VAC (EUR) / 110 VAC (North America)
secondary 24 VAC
Drive system: Poly-V drive belt
Lift motor: lift force 135 kg on rear roller, 24 VAC
Elevation range: 0-10 %
Lower board: Tunturi SISU Technology
Running deck: plywood, reversable
Running belt: Whisper Weave 1-ply construction, hot wax treated
Structural frame: steel
STANDARDS:
J6 and J6F comply with the following requirements:
Europe: EMC Directives on electromagnetic compatibility
(89/336/EEC)
Directives on electrical equipment designed for use within
certain voltage
limits (73/237/ EEC)
North America: FCC requirements on electromagnetic compatibility
J6 and J6F are designed to meet the EN precision and safety standards (Class A, EN-957, parts 1
and 6), ETL and TÜV Certificates pending.
OTHER:
Registered design
Applied Tunturi patents: US 5518471 / Exercise treadmill with rearwardly placed
incline mechanism
FIN 982740 / Patent pending
