turck PS Series User Manual

10
IO-Link Parameters – Specific service PDU – Overview
Hans Turck GmbH & Co. KG | Witzlebenstraße 7, 45472 Mülheim/Ruhr, Germany | T +49 208 4952-0 | more@turck.com | www.turck.com
4.4 Specic service PDU – Overview
Index
(hexa-
decimal)
Parameters
Name
Access
R: Read
W: Write
Byte
Length
Data type Description Default
value
See
page
0x51 Ou1 RW 1 Unsigned8 Function of output 1 0x00 11
0x52 Ou2 RW 1 Unsigned8 Function of output 2 Li2UPN
LUUPN
2UPN
0x04
0x08
0X00
11
12
0x53 P-n RW 1 Unsigned8 Behavior switching output 0X00 12
0x54 Uni RW 1 Unsigned8 Display unit 0x00 12
0x55 diS RW 1 Unsigned8 Display setting 0x00 13
0x58 Menu locked RW 1 Unsigned8 Locking the menu 0x00 13
0x59 IO-Link write
protection
RW 1 Unsigned8 IO-Link parameter with write
protection
0x00 13
0x60 Sp1/rP1
(FH1/FL1)
RW 4 Record of 2
Unsigned16
Switch/reset point 1 SP: 0x2000
rP: 0x1000
13
13
0x61 Sp2/rP2
(FH2/FL2)
RW 4 Record of 2
Unsigned16
Switch/reset point 2
(not for LUUPN)
SP: 0x2000
rP: 0x1000
13
0x62 ASP/AEP RW 4 Record of 2
Unsigned16
Start value/end value of the
analog range (not for 2UPN)
ASP see below
AEP:0x3AFF
14
0x68 cof RW 2 Signed16 Offset adjustment 0x0000 14
0x69 HI R 2 Unsigned16 Stored max. value – 14
0x6A LO R 2 Unsigned16 Stored min. value – 14
0x70 dAA RW 2 Unsigned16 Damping of the analog output 0x0000 14
0x71 dAP RW 2 Unsigned16 Damping of switching output/
switching outputs
0x0000 15
0x78 dsp1 RW 2 Unsigned16 Switching delay of
switch point of output 1
0x0000 15
0x79 drp1 RW 2 Unsigned16 Switching delay of reset
switch point of output 1
0x0000 15
0x7A dsp2 RW 2 Unsigned16 Switching delay of
switch point of output 2
(not for LUUPN)
0x0000 15
0x7B drp2 RW 2 Unsigned16 Switching delay of reset
switch point of output 2
(not for LUUPN)
0x0000 15
Index 0x62: Default values for ASP (Start value of the analog range)
Type Measuring range Default value
PS01VR -1…0 bar 0x0500
PS0.25V -0.25…+0.25 bar 0x2000
PS001R 0…+1 bar 0x0500
PS001V -1…+1 bar 0x2000
PS003V -1…+2.5 bar 0x146D
PS010V -1…+10 bar 0x09E9
PS016V -1…+16 bar 0x082D
PS025V -1…+25 bar 0x0714
