turck PS Series User Manual

5
2018/10
2 Notes on the Product
2.1 Product identication
These instructions apply to the pressure sensors of the PS-Series.
2.2 Manufacturer and service
Hans Turck GmbH & Co. KG
Witzlebenstraße 7
45472 Mülheim an der Ruhr
Germany
Turck supports you with your projects, from initial analysis to the commissioning of your ap-
plication. The Turck product database contains software tools for programming, configuration
or commissioning, data sheets and CAD files in numerous export formats. You can access the
product database at the following address: http://www.turck.de/products/
Should you have any further questions, please contact the sales and service team in Germany
on the following telephone numbers:
Sales: +49 208 4952-380
Technology: +49 208 4952-390
Outside Germany, please contact your Turck representative.
5 01
Mechanical version
–
Process connection
01 G1/4" female thread
02 1/4"-18NPT female thread
03 1/4"-18NPT male thread
04 G1/4" male thread
05 7/16" UNF male thread
(only for design 5)
06 G3/4" male thread front-
flush (only for design 6)
07 1 1/2" Tri-Clamp
(only for design 6)
08 G1/2" male thread mano-
meter connection (only for
design 5)
09 G1/2" male thread front-
flush (only for design 6)
10 R 1/4" male thread
11 R 1/4" female thread
Design
3 Adjustable, with display,
non-rotatable sensor body
5 Adjustable, with display,
rotatable sensor body
6 Adjustable, with display,
rotatable sensor body with
front-flush membrane
PS 010V – 5 01 – LI2UPN 8 X – H1 1 4 1 / 3GD
LI2UPN 8 X
Electrical version
–
Indication
X… LED display
Voltage range
8 15 (18)…30 VDC
Output function
2UPN 2 switching
outputs/IO-Link
LI2UPN Switching
output/IO-Link
and additional
switching or
analog output
(current/voltage)
PS 010V
Functional principle –
Measuring range
01VR -1…0 bar g
1)
001R 0…1 bar g
1)
0.25V -0.25…0.25 bar g
1)
001A 0…1 bar a
1)
003A 0…2.5 bar a
1)
010A 0…10 bar a
016A 0…16 bar a
025A 0…25 bar a
001V -1…1 bar g
1)
003V -1…2.5 bar g
1)
010V -1…10 bar g
016V -1…16 bar g
025V -1…25 bar g
040V -1…40 bar g
100R 1…100 bar g
250R 1…250 bar g
400R 1…400 bar g
600R 1…600 bar g
2)
Functional principle
PS Pressure sensor
g = Relative pressure
a = Absolute pressure
1)
Not available for design/
process connection 609
2)
Not available for design 6
3GD
Special version
Special version
3GD Ex zone
H1 1 4 1
Electrical connection:
Connector
/
Assignment
1 Standard assignment
Number of contacts
4 4 contacts
Design
1 Straight
Connector type
H1 Connector, M12 x 1
