turck PS Series User Manual

11
2018/10
Type Measuring range Default value
PS040V -1…+40 bar 0x0651
PS100R 0…+100 bar 0x0500
PS250R 0…+250 bar 0x0500
PS400R 0…+400 bar 0x0500
PS600R 0…+600 bar 0x0500
PS001A 0…+1 bar 0x0500
PS003A 0…+2.5 bar 0x0500
PS010A 0…+10 bar 0x0500
PS016A 0…+16 bar 0x0500
PS025A 0…+25 bar 0x0500
4.5 Specic service PDU
Index 0x51: Function of output 1
Value (hexadecimal) Menu item Function
0x00 Hno Hysteresis function N/O = NO contact
0x01 Hnc Hysteresis function N/C = NC contact
0x02 Fno Window function N/O = NO contact
0x03 Fnc Window function N/C = NC contact
Index 0x52: Function of output 2
Value (hexadecimal) Menu item Function
0x00 Hno Hysteresis function N/O = NO contact
0x01 Hnc Hysteresis function N/C = NC contact
0x02 Fno Window function N/O = NO contact
0x03 Fnc Window function N/C = NC contact
For LI2UPN:
Value (hexadecimal) Menu item Function
0x00 Hno Hysteresis function N/O = NO contact
0x01 Hnc Hysteresis function N/C = NC contact
0x02 Fno Window function N/O = NO contact
0x03 Fnc Window function N/C = NC contact
0x04 4 - 20 4…20 mA linear increase
0x05 0 - 20 0…20 mA linear increase
0x06 20 - 4 20…4 mA linear decrease
0x07 20 - 0 20…0 mA linear decrease
0x08 0 - 10 0…10 V linear increase
0x09 0 - 5 0…5 V linear increase
0x0A 1 - 6 1…6 V linear increase
0x0B 10 - 0 10…0 V linear decrease
0x0C 5 - 0 5…0 V linear decrease
0x0D 6 - 1 6…1 V linear decrease
