turck PS Series User Manual

12
IO-Link Parameters – Specific service PDU
Hans Turck GmbH & Co. KG | Witzlebenstraße 7, 45472 Mülheim/Ruhr, Germany | T +49 208 4952-0 | more@turck.com | www.turck.com
For LUUPN:
Value (hexadecimal) Menu item Function
0x08 0-10 0…10 V linear increase
0x09 0- 5 0…5 V linear increase
0x0A 1- 6 1…6 V linear increase
0x0B 10-0 10…0 V linear decrease
0x0C 5 -0 5…0 V linear decrease
0x0D 6 -1 6…1 V linear decrease
Index 0x53: Behavior of the switching outputs
Value (hexadecimal) Menu item Function
0x00 PnP p switching
0x01 nPn n switching
Index 0x54: Unit shown in the display
Value (hexadecimal) Menu item Function
0x00 bAr bar
0x01 PSi psi
0x02 kPA kPa
0x03 MPA MPa
0x04 Ud 1 Millibar = Hectopascal
0x05 Ud 2 mm Hg (0 °C) = Torr
0x06 Ud 3 Inch of water (60 °F)
0x07 Ud 4 Inch of water (39 °F)
0x08 Ud 5 Foot of water (39 °F)
0x09 Ud 6 Inch of Hg (60 °F)
0x0A Ud 7 Inch of Hg (32 °F)
0x0B Ud 8 mH
2
O (16 °C)
0x0C Ud 9 mH
2
O (4 °C)
0x0D Ud10 kg / cm²
For pressure sensors, only displayable units are shown on the display. These depend on the end
value of the measuring range. The following table shows the supported measuring units:
Measuring range
end
bar psi kPa Mpa Ud1 Ud2 Ud3 Ud4 Ud5 Ud6 Ud7 Ud8 Ud9 Ud10
1 bar + + + + + + + + + + + + + +
3 bar + + + + + + + + + + + + + +
10 bar + + + + – + + + + + + + + +
16 bar + + + + – – + + + + + + + +
25 bar + + + + – – – – + + + + + +
40 bar + + + + – – – – + + + + + +
100 bar + + – + – – – – + + + + + +
250 bar + + – + – – – – + + + + + +
400 bar + + – + – – – – – – – + + +
600 bar + + – + – – – – – – – + + +
