6.2 TPMS Receiver Installation
(Fig 1) Clean the windshield where the receiver will be adhered to and allow to dry. Attach the TPMS
receiver to the suction cup holder and adjust the receiver to the proper angle. Press the suction cup holder
against the desired location on the windshield. Make sure that the antenna is not bent or damaged during
the installation.
(Fig 2) Insert the power cable into the bottom of the receiver.
(Fig 3) Insert the cigarette lighter side of the power cable into the cigarette lighter socket to supply power
to the receiver.
(Fig 4) Press the red “PUSH ON” button on the cigarette lighter power cable to power the Receiver.
