Parts List
Parts List for Model 540 to 720 Series – Mechanical Splash Lube
ITEM
NO.
PART DESCRIPTION QTY
1 ROTOR
2
3 HOUSING
1
4 ENDPLATE
2
6 COVER D.E.
1
7 COVER F.E.
1
8 GEAR ASSEMBLY
1
9 BEARING, BALL, 2 ROW
2
10 BEARING, ROLL CYLINDER
2
14 BEARING RETAINER
2
21 SLINGER, OIL
1
22 PIN, DOWEL, 3/8 X 7/8
6
23 KEY,1/4 SQUARE X 1 3/4
1
24 KEY, GEAR TIMING
2
25 WASHER, ROTOR SHAFT
1
26 SCREW, CAP, HEX HEAD, 5/16
28
29
SCREW, CAP, SOCKET HEAD,
3/8
1
31
PLUG, MAG, 3/8 SQUARE
HEAD
2
35 LOCKNUT, GEAR
2
36 WASHER, GEAR LOCK
2
38 PORT, 4 FLANGE
2
40 SCREW, CAP, HEX HEAD, 3/8
28
42 NAMEPLATE
1
45 SHAFT DRIVE
1
50 BEARING, BALL, 2 ROW
1
51 SEAL,LAB
4
54 SEAL, MECH
4
62
SCREW, CAP, FLATHEAD, #10
NYLOK
8
65 PLATE, LOCK, DRIVE SHAFT
2
66 SCREW, CAP, HEX HEAD
4
68 PIN, DOWEL, 1/8 X 1 1/4
1
69
SCREW, CAP, SOCKET HEAD,
3/8
1
74 SPACER
1
75 O-RING, VITON
1
76 SEAL,MECH
1
77 SPACER - DRIVE SHAFT
1
82 WASHER DUST
1
ITEM
NO.
PART DESCRIPTION QTY
83 LOCKNUT
1
85 PLUG, PIPE, 1/4 HEX, STEEL
5
86 SHIM, .010 THICK
2
94
COOLING COIL, BRASS /
COPPER
2
95 O-RING, VITON A
4
96 O-RING, VITON A
4
97 BUSH, MANIFOLD, BRASS
4
98
PLUG, PIPE, 1/8 SQUARE,
STEEL
6
118 SHIM, .003 THICK
1
121
PLUG, PIPE, 3/8 SQUARE,
STEEL
2
123 SPACER
2
166
CONNECTOR, HOSE, 1/4 X 1/8
MPT - BRASS
2
174 PLUG, PIPE, 1/2 HEX, STEEL
1
180
ELBOW, STREET - 1/8" NPT -
BRASS
2
181 HOSE, ID, 1/4
1
195 LIFTING LUG
2
234 TAG, OIL LEVEL
4
241
SCREW, HH CAP 10-32 X .63
STEEL NYLOK
24
242 FRAME, SIGHT GAUGE
4
243
WINDOW, SIGHT GLASS
GAUGE
4
244 GASKET, WINDOW
4
245 GASKET, FRAME
4
500
THERMOSWITCH **35 FT-LB
TORQUE**
1
OTE: N
• QUANTITIES SHOWN ARE MAXIMUM
VALUES. QUANTITIES MAY VARY BETWEEN
BLOWER.
PARTS KITS ARE AVAILABLE. CONSULT
AUTHORIZED REPRESENTATIVE FOR PART
NUMBERS.
