Manual 2003 Rev D p/n 2003
39
Parts List
Parts List for Model 540 to 720 Series – Slinger Splash Lube
ITEM
NO.
PART DESCRIPTION QTY
1 ROTOR 2
3 HOUSING
1
4 ENDPLAT 2
6 COVER D.E 1
7 COVER F.E. 1
8 GEAR ASSEMBLY
1
9 BEARING, BALL, 2 ROW 2
10 BEARING, ROLL CYLINDER 2
14 BEARING RETAINER
2
21 SLINGER, OIL 1
22 PIN, DOWEL, 3/8 X 7/8 6
23 KEY,1/4 SQUARE X 1 3/4 1
24 KEY, GEAR TIMING 2
25 WASHER, ROTOR SHAFT 1
26
OBS, --SCREW, CAP, SOCKET
HEAD, 5/16
28
29 SCREW, CAP, SOCKET HEAD, 3/8 1
31
PLUG, MAGNETIC, 1/2-20
STRAIGHT THREAD
2
35 LOCKNUT, GEAR 2
36 WASHER, GEAR LOCK 2
38 PORT, 4 FLANGE 2
40 SCREW, CAP, HEX HEAD, 3/8 28
42 NAMEPLATE 1
45 SHAFT DRIVE 1
50 BEARING, BALL, 2 ROW 1
62
SCREW, CAP, FLATHEAD, #10
NYLOK
8
65 PLATE, LOCK, DRIVE SHAFT 2
66 SCREW, CAP, HEX HEAD 4
68 PIN, DOWEL, 1/8 X 1 1/4 1
69 SCREW, CAP, SOCKET HEAD, 3/8 1
74 SPACER 1
75 O-RING, VITON 1
76 SEAL,MECH 1
77 SPACER - DRIVE SHAFT 1
79 SLINGER, SEAL STATOR
4
82 WASHER DUST 1
ITEM
NO.
PART DESCRIPTION QTY
83 LOCKNUT 1
85 PLUG, PIPE, 1/4 HEX, STEEL
4
86 SHIM, .010 THICK 1
93
SCREW, CAP, SOCKET HEAD,
1/4-20
4
94
COOLING COIL, BRASS /
COPPER
2
95 O-RING, VITON A 4
96 O-RING, VITON A
4
97 BUSH, MANIFOLD, BRASS
4
98 PLUG, PIPE, 1/8 SQUARE, STEEL 2
118 SHIM, .003 THICK 2
123 SPACER 2
166
CONNECTOR, HOSE, 1/4 X 1/8
MPT - BRASS
2
174 PLUG, PIPE, 1/2 HEX, STEEL 1
180
ELBOW, STREET - 1/8" NPT -
BRASS
2
181 HOSE, ID, 1/4 1
195 LIFTING LUG 2
234 TAG, OIL LEVEL 2
238 SLINGER, SEAL ROTOR 4
241
SCREW, HH CAP 10-32 X .63
STEEL NYLOK
24
242 FRAME, SIGHT GAUGE 4
243
WINDOW, SIGHT GLASS
GAUGE
4
244 GASKET, WINDOW 4
245 GASKET, FRAME 4
329
PLUG, STRAIGHT THREAD, 1/2,
STEEL
2
500
THERMOSWITCH **35 FT-LB
TORQUE**
1
OTE: N
• QUANTITIES SHOWN ARE MAXIMUM
VALUES. QUANTITIES MAY VARY BETWEEN
BLOWER.
PARTS KITS ARE AVAILABLE. CONSULT
AUTHORIZED REPRESENTATIVE FOR PART
NUMBERS.
