Manual 2003 Rev D p/n 2003
40
Parts List
Parts List for Model 540 to 720 Series – C-ange
ITEM
NO.
PART DESCRIPTION QTY
1 ROTOR
2
3 HOUSING
1
4 ENDPLATE 2
6 C-FLANGE COVER DE 1
7 COVER F.E. 1
8 GEAR ASSEMBLY 1
9 BEARING, BALL, 2 ROW
2
10 BEARING, ROLL CYLINDER 2
13 SEAL,LIP
1
14 BEARING RETAINER 2
21 SLINGER, OIL 1
22 PIN, DOWEL, 3/8 X 7/8 6
23 KEY,1/4 SQUARE X 1 3/4 1
24 KEY, GEAR TIMING 2
25 WASHER, ROTOR SHAFT 1
26 SCREW, CAP, HEX HEAD, 5/16 28
29
SCREW, CAP, SOCKET HEAD,
3/8
1
31
PLUG, MAG, 3/8 SQUARE
HEAD
2
35 LOCKNUT, GEAR 2
36 WASHER, GEAR LOCK 2
38 PORT 2
40 SCREW, CAP, HEX HEAD, 3/8 28
42 NAMEPLATE 1
45 SHAFT, DRIVE, 4000 C-FLANGE 1
51 SEAL,LAB 4
54 SEAL, MECH 4
62
SCREW, CAP, FLATHEAD, #10
NYLOK
8
65 PLATE, LOCK, DRIVE SHAFT 2
66 SCREW, CAP, HEX HEAD 4
68 PIN, DOWEL, 1/8 X 1 1/4 1
69
SCREW, CAP, SOCKET HEAD,
3/8
1
76 SEAL,MECH
1
85 PLUG, PIPE, 1/4 HEX, STEEL 4
ITEM
NO.
PART DESCRIPTION QTY
94
COOLING COIL, BRASS /
COPPER
2
95 O-RING, VITON A
4
96 O-RING, VITON A 4
97 BUSH, MANIFOLD, BRASS 4
98
PLUG, PIPE, 1/8 SQUARE,
STEEL
4
121
PLUG, PIPE, 3/8 SQUARE,
STEEL
2
123 SPACER
2
166
CONNECTOR, HOSE, 1/4 X 1/8
MPT - BRASS
2
174 PLUG, PIPE, 1/2 HEX, STEEL 1
180
ELBOW, STREET - 1/8" NPT -
BRASS
2
181 HOSE, ID, 1/4 24
195 LIFTING LUG 2
234 TAG, OIL LEVEL 4
241
SCREW, HH CAP 10-32 X .63
STEEL NYLOK
24
242 FRAME, SIGHT GAUGE 4
243
WINDOW, SIGHT GLASS
GAUGE
4
244 GASKET, WINDOW 4
245 GASKET, FRAME 4
303 C-FLANGE COVER 2
309
SCREW, CAP,SOCKET HEAD,
1/4 X.500 LONG
8
500
THERMOSWITCH **35 FT-LB
TORQUE**
1
OTE: N
• QUANTITIES SHOWN ARE MAXIMUM
VALUES. QUANTITIES MAY VARY BETWEEN
BLOWER.
PARTS KITS ARE AVAILABLE. CONSULT
AUTHORIZED REPRESENTATIVE FOR PART
NUMBERS.
