Manual 2003 Rev D p/n 2003
42
Parts List
Parts List for Model 850 to 2700 Series – Slinger Splash Lube
ITEM
NO.
PART DESCRIPTION QTY
1 ROTOR 2
3 HOUSING 1
4 ENDPLATE 2
6 COVER D.E. 1
7 COVER F.E. 1
8 GEAR ASSEMBLY 1
9 BEARING, BALL, 2 ROW 2
10 BEARING, ROLL CYLINDER 2
14 BEARING RETAINER 2
21 SLINGER, OIL, WELDED 1
22 PIN, DOWEL, 5/8 X 1 1/4 6
23 KEY, 3/8 SQUARE X 2 15/16 1
24 KEY, GEAR TIMING 2
25 WASHER, ROTOR SHAFT 1
26
SCREW, CAP, HEX HEAD, 1/2
x 4-1/4
28
29
SCREW, CAP, SOCKET HEAD,
CS 1/2 X 1
1
31
PLUG, MAGNETIC, 7/8-14 HEX
HEAD
2
35 LOCKNUT, GEAR 2
36 LOCKWASHER, GEAR 2
38 PORT 1
40
SCREW, CAP, HEX HEAD, 1/2
X 1-1/4
20
42 NAMEPLATE 1
45 SHAFT, DRIVE, 1 1/2 DIAMETER 1
48 PORT 1
50
BEARING, BALL,1 ROW W/
SHIELD
1
57 BEARING SPACER 1
62
SCREW, CAP, SOCKET HEAD,
5/16-18 NYLOK
8
65 PLATE, LOCK, DRIVE SHAFT 2
66
SCREW, CAP, HEX HEAD 1/2 X
1-3/4
4
68 PIN, ROLL, 1/4 X 1 1
69
SCREW, CAP, SOCKET HEAD,
CS 1/2X1-3/4
1
74 SPACER 1
75 O-RING, VITON A 1
76 SEAL,MECH 1
ITEM
NO.
PART DESCRIPTION QTY
77 SPACER 1
79 SLINGER, SEAL STATOR 4
82 WASHER DUST 1
83
LOCKNUT, DRIVE SHAFT, N-08
W/NYLON
1
85 PLUG, PIPE, 1/4 HEX, STEEL 9
86 SHIM, TIMING 2
93
SCREW, CAP, SOCKET HEAD,
1/4-20
4
94 COOLING COILS, COPPER 2
95 O-RING, VITON A 4
96 O-RING, VITON A 4
97 BUSH, MANIFOLD, BRASS 4
98 PLUG, PIPE, 1/8 SQUARE, STEEL 5
123 BEARING SPACER 2
166
CONNECTOR, HOSE, 1/4 X 1/8
MPT - BRASS
2
174 PLUG, PIPE, 1/2 HEX, STEEL 5
180
ELBOW, STREET - 1/8" NPT -
BRASS
2
181 HOSE, ID, 1/4 1
195 LIFTING LUG 2
225
SCREW, CAP, HEX HEAD, 1/4-
20 NYLOK
4
234 TAG, OIL LEVEL 2
238 SLINGER, SEAL 4
241
SCREW, HH CAP 10-32 X .63
STEEL NYLOK
12
242 FRAME, SIGHT GAUGE 2
243 WINDOW, SIGHT GLASS GAUGE 2
244 GASKET, WINDOW 2
245 GASKET, FRAME 2
274 HOSE, ID, 1/4 1
372
PLUG, STRAIGHT THREAD, 7/8,
STEEL
2
500
THERMOSWITCH **35 FT-LB
TORQUE**
1
OTE: N
• QUANTITIES SHOWN ARE MAXIMUM
VALUES. QUANTITIES MAY VARY BETWEEN
BLOWER.
