Parts List
Parts List for Model 850 to 2700 Series – C-Flange
ITEM
NO.
PART DESCRIPTION QTY
1 ROTOR 2
3 HOUSING 1
4 ENDPLT (see TB51,53) 2
6 C-FLANGE COVER DE 1
7 COVER F.E. 1
8 GEAR ASSEMBLY 1
9 BEARING, BALL, 2 ROW 2
10 BEARING, ROLL CYLINDER 2
13 SEAL, LIP 1
14 BEARING RETAINER 2
21 SLINGER, OIL, WELDED 1
22 PIN, DOWEL, 5/8 X 1 1/4 6
23 KEY, 5/16 SQUARE X 1 3/4 1
24 KEY, GEAR TIMING 2
25 WASHER, ROTOR SHAFT 1
26
SCREW, CAP, HEX HEAD, 1/2
x 4-1/4
28
29
SCREW, CAP, SOCKET HEAD,
CS 1/2 X 1
1
30
SCREW, CAP, SOCKET HEAD,
5/16-18 NYLOK
8
31
PLUG, MAGNETIC, 1/2 SQUARE
HEAD
2
35 LOCKNUT, GEAR 2
36 LOCKWASHER, GEAR 2
38 PORT 1
40
SCREW, CAP, HEX HEAD, 1/2
X 1-1/4
28
42 NAMEPLATE 1
45 SHAFT, DRIVE 1
48 PORT 1
51 SEAL, LAB 4
54 SEAL, MECH 4
57 BEARING SPACER 1
65 PLATE, LOCK - DRIVE SHAFT 2
66
SCREW, CAP, HEX HEAD 1/2 X
1-3/4
4
68 PIN, ROLL, 1/4 X 1 1
69
SCREW, CAP, SOCKET HEAD,
CS 1/2X1-3/4
1
76 SEAL,MECH 1
85 PLUG, PIPE, 1/4 HEX, STEEL 6
ITEM
NO.
PART DESCRIPTION QTY
94 COOLING COILS, COPPER 2
95 O-RING, VITON A 4
96 O-RING, VITON A 4
97 BUSH, MANIFOLD, BRASS 4
123 BEARING SPACER 2
166
CONNECTOR, HOSE, 1/4 X 1/8
MPT - BRASS
2
174 PLUG, PIPE, 1/2 HEX, STEEL 3
180
ELBOW, STREET - 1/8" NPT -
BRASS
2
181 HOSE, ID, 1/4 26
195 LIFTING LUG 2
234 TAG, OIL LEVEL 2
241
SCREW, HH CAP 10-32 X .63
STEEL NYLOK
24
242 FRAME, SIGHT GAUGE 4
243
WINDOW, SIGHT GLASS
GAUGE
4
244 GASKET, WINDOW 4
245 GASKET, FRAME 4
303 C-FLANGE COVER 2
309
SCREW, CAP,SOCKET HEAD,
1/4 X.500 LONG
8
500
THERMOSWITCH **35 FT-LB
TORQUE**
1
OTE: N
• QUANTITIES SHOWN ARE MAXIMUM
VALUES. QUANTITIES MAY VARY BETWEEN
BLOWER.
PARTS KITS ARE AVAILABLE. CONSULT
AUTHORIZED REPRESENTATIVE FOR PART
NUMBERS.
