10.3 INSTRUCTIONS FOR CONVERTING DRIVES
10.3.1 BOTTOM DRIVE UNITS
If the sight glasses are on the right side as you face the drive shaft you can make a right drive unit by
changing mounting feet, lift lugs, sight glasses and magnetic drain plugs. If the sight glasses are on the left
you can make a left drive unit by changing the same items above.
10.3.2 LEFT OR RIGHT DRIVE UNITS
Can be made bottom drives by changing the same items above.
NOTE
When converting to bottom drive it may be necessary to change the location
of the oil slinger to the bottom rotor.
