TUYA N1TY - Step 4: Install Outdoor Unit; Step 5: Install Mounting Plate; Step 6: Install Indoor Unit

- 5 -
Step 4
Install outdoor unit (A)
Step 5
Install mounting plate (C) on the door
Step 6
Install indoor unit (B) on the door
Note: Install 4 x AAA Alkaline batteries.
A
A
H
B
C
F
Note: Cable goes through the square
hole of back handle.
This side up
Note: Make sure the side with the text "This Side Up"
on the square spindle must be upward.
This side up
G
