TV Logic LVM-245W User Manual

10 Multi Format LCD Monitor
● [MENU] Button/Lamp
- Used to activate the OSD menu.
● [DOWN] Button/Lamp
- Used to move down though the menus
during the OSD menu activation and also
decrease the value of the selected feature.
● [UP] Button/Lamp
- Used to move up though the menus during
the OSD menu activation and also increase
the value of the selected feature.
● [ENTER] Button/Lamp
- Used to conrm a chosen value (or mode).
It may also be used to control the VOLUME
value during OSD menu inactivation.
● [APERTURE] Knob
- Used to adjust the picture sharpness.
- Control value range : 0 ~ 25
- Unavailable in DVI ANALOG Mode.
● [BRIGHT] Knob
- Used to adjust the degree of brightness.
- Control value range : -100 ~ 100
● [CONTRAST] Knob
- Used to adjust the contrast.
- Control value range : -100 ~ 100
● [AUDIO OUT] (PHONE JACK)
- Selects the Left/Right Audio disembedded
signal output or HDMI input signal or
external stereo signal is output through the
internal speaker or the phone jack.
● [USB]
- Ethernet and USB ports for monitor control,
convenient to update the program for new
function and debugging.
● [STANDBY] Lamp
- It aords power supply, which may be
indicated by indication lamp. The lamp is
RED during power supply and GREEN during
system is in operation. In case of power cut
and sudden shut o of the power, our
monitor keep previous setup stage.
● [POWER] Button
- Used to turn power on and o.
● [TALLY] Lamp
- Tally lamp that can be toggled in green or
red using the REMOTE(RJ-45) port.
3. Controls & Functions
FRONT
LVM-245W_327W_V2.0_EN.indd 10 2014-04-10 오후 2:01:55
