Multi Format LCD Monitor 33
1. Press MARKER button to activate the
marker.
2. The selected marker type can be displayed
on the screen when the marker function is
selected from the main menu.
6. Other Functions
[3] MARKER
● This product supports various scan
modes.
● Press the [SCAN] button on the front of
the monitor to activate dierent scan
modes.
1. Press the [SCAN] button continuously to
activate various scan modes.
- OVER SCAN -> ZERO SCAN -> UNDER SCAN
-> 2:1 SCAN -> 1:1 SCAN -> FIT WIDTH ->
USER ASPECT
2. Scan mode types are diered by connected
signal.
- SDI, COMPONENT, RGB, DVI ANALOG,
COMPOSITE 1/2/3, S-VIDEO : OVER SCAN
-> ZERO SCAN -> UNDER SCAN -> 2:1 SCAN
-> 1:1 SCAN -> FIT WIDTH -> USER ASPECT
-> ZOOM(PBP 16:9 mode)
- DVI DIGITAL, HDMI : OVER SCAN -> ZERO
SCAN -> UNDER SCAN -> 2:1 SCAN -> 1:1
SCAN -> USER ASPECT -> ZOOM(PBP 16:9
mode)
3. The following represents the dierent
types of scan mode. When a scan mode
is selected, display skips the next mode if
its required condition is not met.
[4] SCAN
LVM-245W_327W_V2.0_EN.indd 33 2014-04-10 오후 2:01:57
