5. Menu Operations
• STANDARD
- Used to select the color and dynamic rage of
the screen.
- Available options are HD, UHD, DCI-P3, PQ,
HLG, SLog3 and User1/2/3.
# The submenus may be activated in the
User1/2/3 mode only.
• VIDEO RANGE
- Used to select the range of digital video signal.
* FULL : Input signal 0~255 (8bit), 0~1023 (10bit)
(When connecting the PC)
* LIMITED109 : Input signal Y‘: 16~235, CbCr:
16~240 (8bit)/ Y‘: 64~940, CbCr: 64-960 (10bit)
• PEAK LUMINANCE
- Used to select the Peak Luminance of the
monitor.
- Available options are 100, 200, 300, 400, 500,
600, 700, 800, 900, 1000, 2000, 4000 and
10000.
# Activates only in the User1/2/3 mode.
[2] COLOR
• BLACK LEVEL
- The minimum black level of the video signal
can be set dierently depending on the
performance of the monitor or the lighting
environment.
For example, the lowest luminance that the
F-5A can display is 0.002, but it is necessary
to adjust the oset level to about 0.2nit when
using under bright light. At this time, when the
black level is set to 0.2, dark gradations below
0.2 nit are expressed without crushing.
# Activates only in the User1/2/3 mode.
• COLOR GAMUT
- Used to select the standard color gamut.
- Available options are BT.709, DCI-P3, BT.2020
and Native.
# The submenus may be activated in the
User1/2/3 mode only.
• COLOR TEMP
- Controls color temperature and allows instant
access to preset color temperature settings.
- Available color temperatures is 6500K.
- In User 1/2/3 modes, user can dene custom
RGB GAIN and BIAS (=Oset) values.
• EOTF
- Used to select the Electrophotic conversion
Functions(ex: Gamma or HDR curve).
- Available modes are 2.2, 2.4, 2.6, PQ, HLG and
SLOG3.
# The submenus may be activated in the
User1/2/3 mode only.
• LOCAL DIMMING
- Used to set the Local Dimming Backlight
mode.
- This mode is supported by the local dimming
backlight model (LUM-310R) and does not
support F-5A.
COLOR같이 F-5A
STANDARD
VIDEO RANGE
PEAK LUMINANCE
BLACK LEVEL
COLOR GAMUT
COLOR TEMP
EOTF
LOCAL DIMMING
EETF
HLG SG
SG
CAM LUT
CAM LUT THROUGH
UHD
NARROW
100
0.001
BT.2020
6500K
2.4
OFF
OFF
OFF
OFF
OFF
PAG E(1/2)
