10. Product Specifications
*
The specication above may be changed without notice.
*
When using a DC Adapter other than the one supplied by the manufacturer, please be advised that
the adapter with DC 12V/3A ~ 6A can be compatible with the monitor.
F-5A
LCD
Size 5.5”
Resolution 1920×1080(16:9)
Pixel Pitch 0.0213(W) x 0.0639(H) mm
Color Depth 16.7M (True)
Viewing Angle H : 160 degrees / V : 160 degrees
Luminance of white
500 cd/ m
2
(Center)
Contrast Ratio 1,000 : 1
Display Area 122.7(H)x69.0(V) mm
Input
1 X HDMI HDMI V1.2 Input 1Ch
1 X BNC 3G/HD/SD SDI Input 1Ch
Output
1 X HDMI HDMI-HDMI, SDI-HDMI (Conversion)
1 X BNC 3G/HD/SD SDI Output 1Ch, HDMI-SDI (Converision)
Input Signal
3G-SDI 2.970Gbps
HD-SDI 1.485Gbps
SD-SDI 270 Mbps
HDMI 480i / 480p / 576i / 576p / 720p / 1080i / 1080p
SDI Input Signal
Formats
SMPTE-425M-A/B
1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF)
1080i(60/59.94/50)
SMPTE-274M
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
SMPTE-296M 720p (60/59.94/50)
SMPTE-125M 480i (59.94)
ITU-R BT.656 576i (50)
Audio In SDI Embedded Audio (Group, Ch Selectable)
Audio Out External Output Port (3.5m Phone Jack)
Power DC 6V 1.25A/34V 0.27A
Power Consumption (Approx.) TBD
Tally Signal In/Out Level DC5V ±2V
Operating Temperature
0℃ to 40℃ (32
℉
to 104
℉
)
Storage Temperature
-20℃ to 60℃ (-4
℉
to 140
℉
)
Main Body Dimensions (mm/inch) 162.5 X 92 X 35.8 (6.4 X 3.62 X 1.41)
Box Dimensions (mm/inch) 225 X 155 X 128 (8.85 X 6.10 X 5.03)
Weight 0.42Kg / 0.92 lbs
Basic Accessories
Acylic Filter, DC Power adapter, AC Power Cord, BNC Connector (Angle Type),
Camera Mount
Optional Accessories
Carrying Case, Sun-Hood, Tripod Ball Head, HDMI Bracket, Battery Bracket,
Battery Adapter, D-Tap cable
