TVLogic F-5A User Manual

FHD Viewnder Monitor 6
• Compatible with various SDI signals
formats (SD/HD/3G)
- This product is compatible with various SDI
signals - 480i, 576i, 720p, 1080i, 1080p, 1080psf
• HDMI(with HDCP) Signal
- This product is compatible with various HDMI
signals.
• HDMI To SDI / SDI To HDMI Conversion
Output
- This product features an HDMI To SDI
conversion output so that video source from
HDMI In terminal can be output through SDI
Out terminal.
- The SDI To HDMI conversion output is also
supported. The video source from SDI In
terminal can be output through HDMI Out
terminal.
• All-in-one type system
- Slim and all-in-one type monitor that requires
no additional accessories, for optimized space
utilization..
• Waveform/Vectorscope/Audio Level Meter
Function
- Waveform & Vector Scope
- Embedded Audio Level Meter
• Audio Out
- Stereo Audio Out through phone Jack
• Knob Control
- Easy to adjust user conguration using the
control knob on the top of the monitor.
• BLUE ONLY / MONO / Focus Assist/ H/V
Delay Function
• Range Error/Luma(Y’) Zone Check(Color/
Zebra Type) Function
• Internal Pattern Generator (0~100% Gray/
ColorBar+Pluge)
• Various Markers & Safety Areas
- Center Marker, Safety Area Marker, Marker Mat,
Marker Size, Fit Marker, Thickness Adjustment
function
• Pixel To Pixel/Zoom Function
- Used to display the original image resolution
without scaling to match a certain resolution
or an aspect ratio.
- Select ‘Pixel to pixel’ to display unscaled
images, and select ‘Zoom’ to enlarge the
original image.
- Zoom Scroll Function (Left/Right, Top/Bottom)
• Power
- Basically, the product is powered by a normal
DC source.
- The product can be battery-powered.
* DC 6V 1.25A/34V 0.27A (Typical)
• Additional features
- Camera Mounting Hole x 8, Screen Tally
Function, VESA Mounting Standard, 500cd/
m
2
Brightness, 1,000 : 1 Contrast, OSD user
interface.
F-5A Monitor contains the following features :
2. Main Features
