7. Other Functions
[9] HDMI To SDI Conversion-Out
• Video source from ‘HDMI input’ terminal
can be output through ‘SDI throughout’
terminal.
※ Note: HDSLR camera manufacturers usually
specify the resolution and frame rate for the
recording. The signal format that is output
through HDMI terminal of cameras may dier
from makers to makers. The signal format for
HDMI output and playback function of Canon
HDSLRs is 59.94i. And even though 60i or 60p
is specied in the specication of the cameras,
the actual recording or HDMI output format
would be 59.94i or 59.94p.
Viewnder Monitor 33
[10] SDI To HDMI Conversion-Out
Output
Format
Input
Format
1080p50 1080p60
480i(NTSC)
●
576i(PAL)
●
480P
●
576P
●
720P50
●
720P59.94
●
720P60
●
1080i50
●
1080i59.94
●
1080i60
●
1080p24
●
1080p25
●
1080p30
●
1080psF24
●
1080p50
●
1080p59.94
●
1080p60
●
    


Output
Format
Input
Format
1080p50 1080p60
480i(NTSC)
●
576i(PAL)
●
720P50
●
720P59.94
●
720P60
●
1080i50
●
1080i59.94
●
1080i60
●
1080p24
●
1080p25
●
1080p30
●
1080psF24
●
1080p50
●
1080p59.94
●
1080p60
●
    

● 3G/HD/SD SDI signals from‘SDI input’
terminal can be output through‘HDMI
out’terminal.
