TVLogic F-7H mk2 User Manual

FHD High Bright Field Monitor 12
5. Menu Operations
• BLACK LEVEL
- The minimum black level of the video signal
can be set dierently depending on the
performance of the monitor or the lighting
environment. For example, the lowest
luminance that the F-7H mk2 can display is
0.002, but it is necessary to adjust the oset
level to about 0.2nit when using under
bright light.
- At this time, when the black level is set to
0.2, dark gradations below 0.2 nit are
expressed without crushing.
- Activates only in the User1/2/3 mode.
• COLOR GAMUT
- Used to select the standard color gamut.
- Available options are BT.709, DCI-P3,
BT.2020 and Native.
# The submenus may be activated in the
User1/2/3 mode only.
• COLOR TEMP
- Controls the color temperature.
- Available options are 6500K, 9300K and User.
# The submenus may be activated in the
User1/2/3 mode only.
• EOTF
- Electrophotic conversion Functions(ex:
Gamma or HDR curve).
- Available modes are 2.2, 2.4, 2.6, PQ, HLG
and SLOG3.
# The submenus may be activated in the
User1/2/3 mode only.
• LOCAL DIMMING
- Used to set the Local Dimming Backlight
mode.
- This mode is supported by the local dimming
backlight model (LUM-310R) and does not
support F-7H mk2.
• STANDARD
- Used to select the color and dynamic rage
of the screen.
- Available options are HD, UHD, DCI-P3, PQ,
HLG, SLog3 and User1/2/3.
# Activates only in the User1/2/3 mode.
• VIDEO RANGE
- Used to select the range of digital video
signal.
* FULL : Input signal 0~255 (8bit), 0~1023
(10bit) (When connecting the PC)
* LIMITED109 : Input signal Y‘: 16~235, CbCr:
16~240 (8bit)/ Y‘: 64~940, CbCr: 64-960
(10bit)
• PEAK LUMINANCE
- Used to select the Peak Luminance of the
monitor.
- Available options are 100, 200, 300, 400,
500, 600, 700, 800, 900, 1000, 2000, 4000
and 10000.
- Activates only in the User1/2/3 mode.
[2] COLOR
COLOR같이 F-7H mk2
STANDARD
VIDEO RANGE
PEAK LUMINANCE
BLACK LEVEL
COLOR GAMUT
COLOR TEMP
EOTF
LOCAL DIMMING
EETF
HLG SG
SG
CAM LUT
CAM LUT THR
UHD
NARROW
100
0.001
BT.2020
6500K
2.4
OFF
OFF
OFF
OFF
OFF
PAGE (1/2)
