8. Available Signal Formats
Input Signal
"Display Character
Example"
SDI HDMI
VIDEO
480 / 59.94i (NTSC) 720x480 60i
● ●
480 / 60p 720x480 60p
●
576 / 50i (PAL) 720x576 50i
● ●
576 / 50p 720x576 50p
●
720 / 23.98p 1280x720 24p
●
720 / 24p 1280x720 24p
●
720 / 25p 1280x720 25p
●
720 / 30p 1280x720 30p
●
720 / 50p 1280x720 50p
● ●
720 / 59.94p 1280x720 60p
● ●
720 / 60p 1280x720 60p
● ●
1080 / 23.98PsF 1920x1080 48i
●
1080 / 24PsF 1920x1080 48i
●
1080 / 25PsF 1920x1080 50i
●
1080 / 23.98p 1920x1080 24p
● ●
1080 / 30PsF 1920x1080 60i
●
1080 / 29.97PsF 1920x1080 60i
●
1080 / 24p 1920x1080 24p
● ●
1080 / 25p 1920x1080 25p
● ●
1080 / 29.97p 1920x1080 30p
● ●
1080 / 30p 1920x1080 30p
● ●
1080 / 50i 1920x1080 50i
● ●
1080 / 50p 1920x1080 25p
● ●
1080 / 59.94i 1920x1080 60i
● ●
1080 / 60i 1920x1080 60i
● ●
1080 / 59.94p 1920x1080 60p
● ●
1080 / 60p 1920x1080 60p
● ●
PC
640 x 400 (70Hz) 640x400 70p
●
640 x 480 (60Hz) 640x480 60p
●
640 x 480 (75Hz) 640x480 75p
●
800 x 600 (60Hz) 800x600 60p
●
800 x 600 (75Hz) 800x600 75p
●
1024 x 768 (60Hz) 1024x768 60p
●
1024 x 768 (70Hz) 1024x768 70p
●
1024 x 768 (75Hz) 1024x768 75p
●
1280 x 768 (60Hz) 1280x768 60p
●
1280 x 800 (60Hz) 1280x800 60p
●
1280 x 1024 (60Hz) 1280x1024 60p
●
1920 x 1080 (60Hz) 1920x1080 60p
●
