TVLogic F-7H mk2 User Manual

FHD High Bright Field Monitor 38
10. Product Specifications
*
The specication above may be changed without notice.
*
When using a DC Adapter other than the one supplied by the manufacturer, please be advised
that the adapter with DC 12V/3A ~ 6A can be compatible with the monitor.
F-7H mk2
LCD
Size 7”
Resolution 1920×1080 (16:9)
Pixel Pitch 0.079(H) X 0.076(W) mm
Color Depth 16.7M
Luminance of white
3600 cd/ m
2
(Max.)
Contrast Ratio 1200 : 1
Display Area 151.2(H)x94.5(V) mm
Input
1 X HDMI HDMI Input 1Ch
1 X BNC 3G/HD/SD SDI Input 1Ch
Output
1 X HDMI HDMI Output 1Ch
1 X BNC 3G/HD/SD SDI Output 1Ch
Input Signal
3G-SDI 2.970Gbps
HD-SDI 1.485Gbps
SD-SDI 270 Mbps
HDMI 480i / 480p / 576i / 576p / 720p / 1080i / 1080p
SDI Input Signal
Formats
SMPTE-425M-A/B
1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF)
1080i(60/59.94/50)
SMPTE-274M
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
SMPTE-296M 720p (60/59.94/50)
SMPTE-125M 480i (59.94)
ITU-R BT.656 576i (50)
Audio In SDI Embedded Audio (Group, Ch Selectable)
Audio Out External Output Port (3.5m Phone Jack)
Power DC 12V 1.8A
Power Consumption (Approx.) 19W
Tally Signal In/Out Level DC5V ±2V
Operating Temperature
0℃ to 40℃ (32
℉
to 104
℉
)
Storage Temperature
-20℃ to 60℃ (-4
℉
to 140
℉
)
Main Body Dimensions (mm/inch) 211 X 125 X 28.3 (8.3 X 4.95 X 1.11)
Box Dimensions (mm/inch) 290 X 158 X 83 (11.42 X 6.22X 3.27)
Weight 0.76Kg / 1.68 lbs
Basic Accessories BNC Connector, Camera Mount, D-Tap cable
Optional Accessories
Tripod Ball Head, Camera Mount, Battery Bracket,, V-mount, G-Mount, ,
HDMI Bracket, Carrying Case
