03 CONTROLS & FUNCTIONS
15
4K /UHD HDR Emulation LCD Monitor
LUM-181H / 181G / 242H / 242G / 328G / 550H : FRONT
● [HDMI] Button/Lamp
- Used to select HDMI input.
● [SINGLE] Button/Lamp
- Used to select SDI input for one channel.
Previously selected SDI input selecon
displays.
- Press the buon to move through the modes:
SDI-A → SDI-B → SDI-C → SDI-D
● [2SI] Button/Lamp
- Used to select the SDI 2-Sample Interleave
input signal(quad link or dual link).
- Press the button to move through the modes
: 2SI(4CH) → 2SI(2CH)
● [QUAD] Button/Lamp
- Used to select the SDI Quad link square
division input signal.
● [F1 ~ F5] Button/Lamp
- Shortcut key for KEY MAPPING feature in the
OSD MENU.
- Selectable funcon are as follows :
1) Blue Only
- Activates in the order of [Blue Only] → [Mono]
→ [Off].
- Blue Only: Used to remove red and green
from the input signal and display the screen
only under a blue signal.
- Mono: Used to remove all colors from the
input signal and display the screen only
under white and black signal.
2) H/V Delay
- Used to check horizontal and vertical sync
simultaneously by moving the screen up/
down/left/right.
3) White Point
- This function activates when [Standard] -
[User1/2/3/4/5/6] is selected.
- Refer to the page 16.
4) Audio Level Meter
- Refer to the page 26.
5) Time Code
- Refer to the page 27.
6) Luma(Y') Zone
- Refer to the page 24.
7) Focus Assist
- Refer to the page 25.
8) Marker
- Refer to the page 21.
9) DR Mode
- Used to select the dynamic range mode in
the order of SDR → HDR → User.
- SDR : Standard Dynamic Range Mode
- HDR : High Dynamic Range Mode
- User : Custom Dynamic Range Mode
10) Standard
- Refer to the page 16.
11) Disp Luminance
- Refer to the page 16.
12) EOTF
- Refer to the page 16.
13) Video Range
- Refer to the page 16.
14) Waveform
- Refer to the page 23.
15) Scan
- Refer to the page 10.
16) Aspect
- Refer to the page 10.
17) Native Mode
- Used to display the original colors of the
LCD panel.
18) Gumat Warning
- Refer to the page 17.
19) Shadow Mode
- To be supported.
20) 4K Align
- Refer to the page 15.
