03 CONTROLS & FUNCTIONS
16
4K /UHD HDR Emulation LCD Monitor
LUM-181H / 181G / 242H / 242G / 328G / 550H : FRONT
● [SCAN] Button
- Used to select [Zero Scan] and [Over Scan].
● [ASPECT] Button
- Used to select ASPECT mode.
- Available aspect modes are [FULL], [4:3],
[2.35:1], [1.85:1], [15:9], [16:9], [16:10],
[AUTO].
● [MARKER] Button
- Used to acvate/deacvate the Marker.
● [B. LIGHT] Button
- Used to adjust the backlight level.
- Turn the ENTER knob left or right to adjust
the value.
● [VIDEO RANGE] Button
- Used to select the video range.
- Available modes are [Narrow 100%],
[Narrow 109%], [SDI Full].
- This function activates when [Standard] -
[User1/2/3/4/5/6] is selected.
● [INFO.] Button
- Used to activate the information window.
- Refer to the page 29 for the details.
● [MENU/EXIT] Button
- Used to acvate/deacvate the OSD menu.
- Press the MENU buon again to deacvate
the OSD menu.
● [UP/DOWN/ENTER] Knob
- Used to move up/down through the menus
during the OSD menu acvaon and also to
increase/decrease the value of the selected
feature.
- Press the Knob to conrm a chosen value
(or mode).
- May also be used to control the [Backlight] -
[Brightness] - [Contrast] - [Volume] value
during
the OSD menu inacvaon. Turn the Knob to
the le/right to adjust the value.
● [POWER INDICATOR] Lamp
- Indicates condion and power status of unit.
- Light turns o when the power is disconnected.
- Standby mode is indicated by a red LED light.
- Normal (acve) mode is indicated by a
Green LED light.
- The Green light turns o when the monitor
is Normal(acve) mode without input signal.
● [POWER] Button
- Used to turn the power on and o.
- Hold the Power buon for 3 seconds to
turn o the unit. This is to prevent the unit
from being turned o by touching the Power
buon by accident.
● [Audio out] (PHONE JACK)
- Selects the le/right Audio embedded signal
output.
● [USB]
- Used to update the new firmware.
- Used to calibrate the monitor’s color
temperature using color calibraon tool.
