TVLogic LUM-181H User Manual

03 CONTROLS & FUNCTIONS
17
4K /UHD HDR Emulation LCD Monitor
● [REMOTE] (RJ-45)
- Provides connecon to control
equipment(parallel switch) for external
monitor control.
- Features can be changed in the GPI secon of
the OSD menu.
● [RS422 IN/OUT] (RJ-45)
- Used to control the monitor with a protocol
provided by TVLogic.
● [HDMI]
- Signal input terminal for HDMI signal.
● [SDI-A/B/C/D] (BNC)
- SDI signal input terminal.
- SDI-A/B support 12G/6G/3G/HD-SDI input.
- SDI-C/D support 3G/HD-SDI input.
● [SDI-A/B/C/D Output] (BNC)
- SDI signal loop-out terminal.
- SDI-A/B support 12G/6G/3G/HD-SDI output.
- SDI-C/D support 3G/HD-SDI output.
* SDI Output is not activated when the
unit is turned o or in Standby mode.
● [AUDIO IN]
- Used to connect the audio input signal.
● [LAN]
- Used to control the monitor with a protocol
provided by TVLogic.
● [AC IN]
- LUM-181H: 100~240V (50/60Hz)
- LUM-242H: 100~240V (50/60Hz)
● [DC IN]
- LUM-181H: DC 12V/8A ~ 24V/4A
- LUM-242H: DC 24V/6.5A
<WARNING!!>
When using the product make sure to ground,
whenever possible, before connecng the
input signal cable in order to prevent any
possible damage to the product or connected
devices. The damage may include signal noise,
malfuncon of main board or display panel.
And the connected devices such as camera or
video source player may also be inuenced
through signal cable. Please check if the AC
power source and the power extender or
power distributor is grounded.
LUM-181H / 181G / 242H / 242G / 328G / 550H : REAR
